4.5 Meter C Band RxO Circular Polarity Antenna 1451

The CPI Antenna Technologies’ 4.5m C-Band RxO Antenna Series 1451 is ideally suited for demanding commercial applications. The 8-piece compression molded reflector is precision manufactured for high-efficiency operation. The Az/El mount is designed for installation on a custom Kingpost (included) of 10” Schedule Pipe (10.75” or 273 mm OD) The Az/El mount features fine Azimuth and Elevation Adjustments. All structural components are constructed from heavy gauge galvanized steel for strength and corrosion resistance. The electrical performance is compliant with FCC and ITU-RS-580 sidelobe specifications and Intelsat (A, B, C) and Eutelsat requirements.

4.5 Meter C Band RxO Linear Polarity Antenna 1451

The CPI Satcom & Antenna Technologies Inc. (CPI SAT) 4.5m C-Band RxO Antenna Series 1451 is ideally suited for demanding commercial applications. The 8-piece compression molded reflector is precision manufactured for high-efficiency operation. The Az/El mount is designed for installation on a custom Kingpost (included) of 10” Schedule Pipe (10.75” or 273 mm OD) The Az/El mount features fine Azimuth and elevation adjustments. All structural components are constructed from heavy gauge galvanized steel for strength and corrosion resistance. The electrical performance is compliant with FCC and ITU-RS-580 sidelobe specifications and Intelsat (A, B, C) and Eutelsat requirements.

3.8 Meter C/Ku Band Tx/Rx Dual Axis Antenna 1386

3.8 Meter C/Ku Rx/Tx High Wind Antenna 2385

3.8 Meter C/Ku Band Tx/Rx Antenna 1385

The CPI Satcom & Antenna Technologies Inc. (CPI SAT) 3.8 meter antenna delivers ideally suited for demanding commercial applications. The four (4) piece compression molded reflector is precision manufactured for high-efficiency C or Ku-Band operation. The Az/El mount is designed for installation on 10.75” OD Pedestals, using the supplied pipe flange. The 4-piece reflector construction allows for the ease of handling and increased shipping efficiency. The Series 1385 Antenna is available with a variety of feed options. The Tier-3 Feed Support is ideal for mid to heavy weight RF electronics packages. For even heavier RF equipment, a feed stabilizer is optional for 1385 Series. (Standard. with Ku-Band models)

3.7 Meter C Band RxO Antenna 1374

CPI SAT’s 3.7m Wide C-Band RxO Antenna Series 1374 is ideally suited for demanding commercial applications. The 8-piece compression molded reflector is precision manufactured for high-efficiency operation. The Az/El mount is designed for easy installation on standard 6” Schedule Pipe (6.63” or 168mm OD) Installation Mounts and features fine Elevation Adjustment. The Az/El mount is constructed from heavy gauge galvanized steel for strength and corrosion resistance.

3.0, 3.4 & 3.7M C or Ku-Band RxO Antenna 1304/1305 1344/1345 1374/1375

2.4 Meter Ka Band Rx/Tx Antenna 3244

CPI Satcom & Antenna Technologies Inc. (CPI SAT) 2.4m Ka-Band VSAT Antenna Series 3244 is ideally suited for demanding commercial applications. The four-piece compression molded reflector is precision manufactured for high-efficiency Ka-Band operation. The heavy-duty back structure provides precision support to the reflector as needed for Ka band performance, and the az/el mount is designed for easy installation on standard 6-5/8” (168mm) OD mounts. A Ka CP feed is matched to the antenna
